DESCRIPTION
Features:
IP65 Waterproof--The waterproof rating is IP65, the product will not be easily damaged.
Natural Cooling--The cooling method adopts natural convection and no fan to ensure that the product will not overheat during operation
Easy To Install And Remove--Excellent performance and complete accessories, easy to install and remove.
LED Display--The LED display can provide clear and intuitive indicator.
High Efficiency--High peak efficiency, the efficiency is 95%.
Specification:
MPPT Voltage Range: 24V-40V.
Working Voltage Range: 18V-50V.
Maximum Input Power: 2 x 250W.
Maximum Input Current: 2 x 10A.
Rated Output Power: 495W.
Nominal Output Current: at 120VAC: 4.16A/ at 230VAC: 2.17A.
Nominal Output Voltage: 120VAC / 230VAC.
Default Output Voltage Range: at 120VAC: 80V-160V / at 230VAC: 180V-280V.
Nominal Output Frequency: 50Hz / 60Hz.
Total Harmonic Distortion: <5%.
Maximum Units Per Branch: at 120VAC: 5 Units / at 230VAC: 9 units.
CEC Weighted Efficiency: at 120VAC: 92.5％/ at 230VAC: 93.5％.
MPPT Nominal Efficiency: 99.9%.
AC Bus Cable Maximum Current: 20A.
Output Connector: M24 + F182.
Cooling Method: Natural convection, no fan.
