DESCRIPTION
Features:
True diversity for a stable signal reception.
Automatic Channel Setting for quick start.
Features (such as Clear Channel Scan, Active Channel Scan and IR Sync) allow for fast, and safe channel setup.
Output level contror receiver.
Large display and simple menu for easy operation.
Adjustable attenator for accepting wide range of sound pressur level.
Line input available.
Sturdy plastic body. Ni-MH battery are not included.
Specifications:
Set Type:Transmitter Sets;
Transmitter Parameters:
The Number of Channels: 50;
Channel:A and B;
Carrier Frequency Range: 530MHz-590MHz;
Deviation: ±5kHz(-60dBv, input 1kHz);
Signal-to-Noise: Higher than 70dB;
Audio Delay: 12ms;
Antenna: 1/4 Lambda Antenna (input);
Audio Input Interface: 3.5mm;
Radio Frequency Output Level: 10mW;
Distortion: 1% less than;
Working Temperature: 0℃~50℃;
Storage Temperature: -20℃~55℃;
Compatible Battery: 2pcs AA batteries;
Receiver Parameters:
The Number of Channels: 50;
Channel: A and B;
Modulation Mode: FM;
Carrier Frequency Range: 530MHz-590MHz;
Deviation: ±5kHz(-60dBv, input 1kHz);
Signal-to-Noise: Higher than 70dB;
Audio Delay:12ms;
Antenna:1/4 Lambda Antenna (input);
Audio output Interface:3.5mm;
Headphone Output Level:30mW (16 Ohms);
Distortion:1% less than;
WorkingTemperature:0℃~50℃;
Storage Temperature:-20℃~55℃;
Compatible Battery:2pcs AA batteries;
Receiving Sensitivity:-95dBm;
Frequency Response:50Hz-15kHz (±3dB);
Colour:Black;
Material:metal + plastic;
Package Contents:
2 * Microphone Transmitter;
1 * Microphone Receiver;
2 * Collar Microphone;
2 * Stereo 3.5mm Mini Plug Cable;
1 * USB Cable;
1 * XLR-BMP Cable;
3 * Hot Shoe Base Plate;
1 * Manual
