DESCRIPTION
Features:
Display the AC voltage and current simultaneously by LED digital tube.
Din-rail installation and easy measurement, just connect to power and lead the wire through the hole.
Wide voltage and current measurement range.
Used to monitor the operation situation of appliances.
Specifications:
Measurement range: AC 80-300V 0.2-99.9A;
Power supply: < 0.2V*A;
Installation: Din-rail;
Accuracy: 1% ± 2digit;
Measurement speed: about 2 times per second;
Display type: 0.5" LED digital tube;
Display size: 5 * 4cm / 2 * 1.6in;
Installation width: = 3P (DZ47/C45, air switch position);
Product size: 8 * 5.5 * 6.5cm / 3.1 * 2.2 * 2.6in;
Product weight: 124g / 4.4oz;
Package size: 8.8 * 7.4 * 6.1cm / 3.5 * 2.9 * 2.4in;
Package weight: 144g / 5.1oz;
Package including:
1 * Digital Din-rail AC Voltmeter / Ammeter
