DESCRIPTION
Feartures:
1) Wireless communication 433/462MHz
2) 6-grade power search
3) Wide voltage input(22-50VDC)
* DC voltage input:22~50VDC
* Second level power variable voltage conversion.
4) High-frequency two-way and one-way grid function
* High frequency direct modulation, AC half wave synthesis;
5) Kinds of frequency output function
* It can apply to 50Hz and 60Hz frequency of AC
* Frequency range: 45Hz ~ 64Hz;
6) Directly connected to the solar panels(do not need to connect the battery)
7) AC 0 angle with high precision auto-detection--- AC switching: 50Hz / 60Hz.
8) Synchronous High-frequency Modulation
Synthetic way: MOSFET full-bridge; 3. High frequency: 50KHz.
9) Pure Sine Wave Output---Use SPWM directly to make pure sine wave output.
10) Power Automatically Locked (APL)
* Automatically powers locked in maximum power point, made output more stable.
11) Constant Current, Constant Power
* Constant current and output power, without any overload, over-current phenomenon.
12) Exactly and timely automatic Island Effect Protection
13) High-Frequency High Conversion Rate---Adapt high frequency converter, the output more efficient.
14) Maximum Power Point Tracking (MPPT)---high-precision (MPPT) operation power.
15) Stack using---Such as: 4 micro inverter of 260W stacking can achieve 1040W. the number of the stacking is unlimited.
16) DC input---Input voltage range: 22V to 50V,PV Panel:
17) AC output---220VAC: 180V - 262V, 50HZ; 110V AC: 80V - 160V, 60HZ.
Maximum Current : 10.5A
Type : On grid solar inverter
