DESCRIPTION
Features:
1200Mbps Wireless-AC Dual Band Router.
Supports 802.11ac standard - the next generation of Wi-Fi.
Easy setup and enjoy a security wireless network in a minute.
Simultaneous 2.4GHz 300Mbps and 5GHz 867Mbps connections for 1.2Gbps of total available bandwidth.
2 dual band external antennas provide stable wireless connections and optimal coverage.
Specifications:
Plug Type: EU, US;
Interface:
4x10/100Mbps LAN PORTS;
1x10/100Mbps WAN PORT;
Button: WPS, Reset;
Antenna: 4*External Antenna;
External Power Supply: 5VDC / 2A;
Wireless Standards: IEEE 802.11ac,IEEE 802.11n, IEEE 802.11g, IEEE 802.11b;
Dimensions ( W x D x H ): 220.0 x 210.0 x 30.5 mm;
Frequency: 2.4GHz and 5GHz;
Signal Rate: 2.4GHz: Up to 300Mbps, 5GHz: Up to 867Mbps;
Reception Sensitivity: 270M: -70dBm@10% PER;
Transmit Power: <20dBm;
Wireless Functions: Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics;
Wireless Security: 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK;
Quality of Service: WMM, Bandwidth Control, WAN Type;
Dynamic IP/Static IP/PPPoE/PPTP/L2TP/BigPond: DHCP, Server, Client, DHCP Client List;
Port Forwarding: Virtual Server,Port Triggering, UPnP, DMZ;
VPN Pass-Through: PPTP, L2TP, IPSec (ESP Head);
Firewall Security: DoS, SPI Firewall;
IP Address Filter/MAC Address Filter/Domain Filter;
IP and for MAC Address Binding;
Environment:
Operating Temperature: 0℃~40℃ (32℉~104℉);
Storage Temperature: -40℃~70℃ (-40℉~158℉);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing;
Package Contents:
1 x Wireless-AC Rotuer;
1 x Power Adapter;
1 x Ethernet Cable;
1 x Quick Installation Guide
