Model |
600-WiFi |
700-WiFi |
800-WiFi |
|||
|
Input Data |
||||||
|
Recommend Solar |
2*300W |
2*350W |
2*400W |
|||
|
Start-Stop voltage |
18~50V DC |
18~50V DC |
18~50V DC |
|||
|
Reccommend PV (Voc) |
24~50V DC |
24~50V DC |
24~50V DC |
|||
|
MPPT |
24~40V DC |
24~40V DC |
24~40V DC |
|||
|
Maxi Input Current |
2*12A |
2*14A |
2*16A |
|||
|
Output Data |
||||||
|
Max Output |
600W |
600W |
700W |
700W |
800W |
800W |
|
Continuous output |
590W |
590W |
650W |
650W |
795W |
795W |
|
Rated voltage |
120V |
230V |
120V |
230V |
120V |
230V |
|
AC workable scope |
80-160V |
180-260V |
80-160V |
180-260V |
80-160V |
180-260V |
|
Rated output current |
5A |
2.6A |
5.4A |
2.8A |
6.6A |
3.4A |
|
Max units per branch |
4PCS |
8PCS |
4PCS |
7PCS |
6PCS |
11PCS |
|
Rrequency |
Auto switch 50/60Hz(47.5-62.5Hz) |
|||||
|
Output Efficiency |
||||||
|
Static MPPT |
0.999 |
|||||
|
Power factor |
>99% |
|||||
|
Max output |
0.95 |
|||||
|
CEC Weighted |
@120V:92.5% |
|||||
|
Self consumption |
<700mW |
|||||
|
THD |
<5% |
|||||
|
Exterior |
||||||
|
Ambient temperature |
- 40℃to +65℃ |
|||||
|
Operating temperature |
- 40℃to +85℃(inverter inside) |
|||||
|
Dimensions（W×H×D） |
185x180x38.5mm |
|||||
|
Weight |
1.5kg |
|||||
|
AC Cable withstand max current |
20A |
|||||
|
Waterproof Rating |
IP65 |
|||||
|
Cooling |
Self-cooling |
|||||
|
Feature |
||||||
|
Communication |
Built-in WiFi |
|||||
|
Isolation |
High frequency transformer isolation |
|||||
|
Power transmission |
Reverse transfer, load priority |
|||||
|
Monitoring System |
Lifetime free |
|||||
|
Protection |
Islanding,Over-temperature,Over / low AC & AC voltage |
|||||
|
Design Standard |
||||||
|
Electromagnetic compatibility |
EN50081.part1EN50082.part1 |
|||||
|
Grid disturbance |
EN61000-3-2 Safety EN62109 |
|||||
|
Grid detection |
DIN VDE 1026 UL1741 |
|||||
|
Certificate |
CE, RoHs, FCC |
|||||
